Install K3s on a Raspberry PI - TLS certificates

·12 mins·
Kubernetes Homelab Rpi Tutorial
Massimiliano Donini
Author
Massimiliano Donini
πŸš€ Freelance Cloud Architect | Based in The Netherlands πŸ‡³πŸ‡± | Ready to collaborate on cutting-edge Azure & .NET projects! πŸ’‘ Let’s talk Azure, .NET, EF Core, ASP.NET Core, Terraform, GitHub, and CI/CD automation. Got a question or an exciting project? Let’s connect! πŸ”₯
Table of Contents
K3s on Raspberry PI - This article is part of a series.
Part 3: This Article

If you have been following along in this series, so far we have configured the master node and added a few worker nodes to the cluster. Now it’s time to implement a fun part, the TLS certificate management for our internally exposed web applications, so without further ado, let’s dive right into it.

Mixing cert-manager, Let’s Encrypt & Cloudflare
#

Cert-manager is a certificate controller for Kubernetes, created by Jetstack and donated to CNCF. Amongst its key features, we are specifically interested in:

  • Automated issuance and renewal of certificates to secure Ingress with TLS
  • Fully integrated Issuers from recognized public and private Certificate Authorities

We will install cert-manager and configure it to request a certificate from Let’s Encrypt CA.

I won’t go into great details on how the certificate issuing process works but, given that our services are not exposed to the internet, we need to pick a Let’sEncrypt challenge that supports this scenario.

Let’s Encrypt challenges
#

As the documentation puts it

“When you get a certificate from Let’s Encrypt, our servers validate that you control the domain names in that certificate using challenges”

Let’s Encrypt supports several challenge types:

  • HTTP-01
  • DNS-01
  • TLS-ALPN-01

Out of those 3, HTTP-01 and TLS-ALPN-01 require your server to be exposed to the internet, while our explicit goal is not to expose any service through the public internet, so the only suitable challenge we can pick is DNS-01.

The DNS-01 challenge
#

The DNS-01 challenge process is represented in the following sequence diagram:

Let's Encrypt DNS01 challenge
The diagram DNS-01 challenge

Tip

If you want to read more about how the ACME protocol works, you can read the internet standard RFC 8555

DNS Registrar
#

I’m using Cloudflare as my registrar because I love their services, their API allows us to automate DNS management, there are a lot of integrations already existing for Cloudflare and it works natively with cert-manager.

Cloudflare is not the only provider supported by cert-manager and the list of all the supported providers for the DNS-01 challenge can be found here.

Install and configure cert-manager
#

We’re using Helm to install cert-manager, so we need to add the Helm repository and then install the chart.

helm repo add jetstack https://charts.jetstack.io
helm repo update
helm upgrade --install cert-manager jetstack/cert-manager \
  --namespace cert-manager \
  --create-namespace \
  --version v1.15.1 \
  --set crds.enabled=true

Generate Cloudflare API token
#

Now that we installed cert-manager, we have to configure it to consume the Cloudflare API. We have to create a Cloudflare API token to allow cert-manager to consume the Cloudflare API, for which the required permissions are:

  • Permissions:

    • Zone - DNS - Edit
    • Zone - Zone - Read
  • Zone Resources

    • Include - All Zones

Now we need to create a Kubernetes secret with the token generated earlier:

kubectl create secret generic cloudflare-api-key-secret \
  -n cert-manager --from-literal=api-key=[YOUR_CLOUDFLARE_API_KEY]

Configure the staging ClusterIssuer
#

When we install cert-manager, it creates some custom resource definitions (CRDs) that we will use to configure various aspects of the certificate request process, two of which are the Issuer or ClusterIssuer. Those resources represent certificate authorities (CAs) that will issue our cluster the TLS certificates.

Both resources are pretty much identical, with the only difference being that the Issuer is namespace scoped, while the other ClusterIssuer is global, so if you use the issuer and need a certificate for services in multiple namespaces, you need to deploy multiple Issuer resources while with the ClusterIssuer one resource will suffice for the whole cluster. For my homelab I’ve picked the ClusterIssuer one.

On the ClusterIssuer we have to configure Let’s Encrypt DNS-01 challenge and point the resource to the secret created earlier used to authenticate towards the Cloudflare API.

Due to the strict rate limiting applied by the Let’s Encrypt production APIs, it’s a good idea to use their staging APIs first and then, only when everything works correctly, we can then create another ClusterIssuer and target Let’s Encrypt production APIs.

Let’s see here below what the configuration looks like:

  1. Create a file file called clusterissuer-staging.yml and paste the following manifest into it:

    apiVersion: cert-manager.io/v1
    kind: ClusterIssuer
    metadata:
      name: letsencrypt-dns01-staging-issuer
    spec:
      acme:
        server: https://acme-staging-v02.api.letsencrypt.org/directory  # Staging API
        email: mail@mail.com                     # your email address for updates
        privateKeySecretRef:
          name: letsencrypt-dns01-staging-private-key # Name of a secret used to store the ACME account private key
        solvers:
        - dns01:
            cloudflare:
              email: mail@mail.com               # your cloudflare account email address
              apiTokenSecretRef:
                name: cloudflare-api-key-secret  # Matches the name of the secret created earlier
                key: api-key                     # Matches the key of the secret created earlier


Caution

Make sure you replace the email in the manifest above.

  1. Create the staging ClusterIssuer in the cluster

    kubectl apply -f clusterissuer-staging.yml


Warn

If you use a different namespace than cert-issuer, you may need to configure the Cluster Issuer Namespace to specify cert-manager in which namespace to look for the Cloudflare secret. Make sure to read the documentation here

Verify staging ClusterIssuer installation
#

To make sure everything is configured correctly, we will create a certificate issue request since we’re using the staging API of Let’s Encrypt, this certificate won’t be used for TLS, only to make sure everything is configured correctly.

Before proceeding, let’s create an A record in Cloudflare that points to the Traefik service created in the first article of the series. To get the IP address let’s use the following command:

kubectl get svc -n traefik
NAME      TYPE           CLUSTER-IP     EXTERNAL-IP     PORT(S)                                    AGE
traefik   LoadBalancer   10.43.63.113   192.168.2.210   80:31468/TCP,443:31486/TCP,443:31486/UDP   13d

Here we are interested in the external IP, so we will create an A record that points to that IP. Please note that we are creating an A record in our DNS that points to a private IP address. This will allow us to resolve the services hosted in K3s using a domain name and use TLS certificates, rather than using the IP.

For this example, I’ve created a temporary A record for the k3s subdomain in the maxdon.tech domain I own that points to 192.168.2.210, it looks like the following:

Type  Name             Content
A     k3s.maxdon.tech  192.168.2.210

After the record has been created, it’s time to test the certificate-issuing process.

  1. Create a test namespace

    kubectl create namespace test-cert

  2. Create a certificate issue request by pasting the following code in a file called test-certificate-staging.yml

    apiVersion: cert-manager.io/v1
    kind: Certificate
    metadata:
      name: test-certificate
      namespace: test-cert
    spec:
      secretName: test-example-tls             # This is the name of the secret that will hold the TLS certificate
      issuerRef:
        name: letsencrypt-dns01-staging-issuer # This should be the name of the staging CLusterIssuer
        kind: ClusterIssuer
      dnsNames:
      - k3s.maxdon.tech                        # This should be the same name of the A record created in Cloudflare earlier


Caution

Make sure you replace the domain k3s.maxdon.tech with your domain.

  1. Create the test certificate in the cluster

    kubectl apply -f test-certificate-staging.yml

  2. Verify that the certificate has been issued with kubectl get certificates and the output should be the following:

kubectl get certificate -n test-cert
NAME               READY   SECRET             AGE
test-certificate   True   test-example-tls    75s

Note

Please note that this step can take up to a couple of minutes when using the DNS-01 challenge!

If the process went well, we now have a secret that contains our certificate, the name of the secret is defined when we create the certificate resource, and we can then inspect the secret using this command:

kubectl describe -n test-cert secrets test-example-tls
Name:         test-example-tls
Namespace:    test-cert
Labels:       controller.cert-manager.io/fao=true
Annotations:  cert-manager.io/alt-names: k3s.maxdon.tech
              cert-manager.io/certificate-name: test-certificate
              cert-manager.io/common-name: k3s.maxdon.tech
              cert-manager.io/ip-sans:
              cert-manager.io/issuer-group:
              cert-manager.io/issuer-kind: ClusterIssuer
              cert-manager.io/issuer-name: letsencrypt-dns01-staging-issuer
              cert-manager.io/uri-sans:

Type:  kubernetes.io/tls

Data
====
tls.crt:  3733 bytes
tls.key:  1679 bytes

As you can see, we have successfully obtained a certificate with the correct common name, we can also see that this certificate has been issued by the staging issuer, so this shouldn’t be used in our services.

Troubleshooting
#

If the certificate-issuing process fails, here are a few things to look out for:

  1. Make sure that the ClusterIssuer is ready

    kubectl get clusterissuer
    NAME                               READY   AGE
    letsencrypt-dns01-staging-issuer   True    2m7s


    If ready is false, try to look at the events of the ClusterIssuer using the following command:

    kubectl describe clusterissuer letsencrypt-dns01-staging-issuer


    I had the following error:

    Status:
    Acme:
    Conditions:
        Last Transition Time:  2024-07-17T12:57:39Z
        Message:               Failed to register ACME account: Get "https://acme-staging-v02.api.letsencrypt.org/directory": dial tcp: lookup acme-staging-v02.api.letsencrypt.org on 10.43.0.10:53: server misbehaving
        Observed Generation:   1
        Reason:                ErrRegisterACMEAccount
        Status:                False
        Type:                  Ready


    This was due to an incorrect configuration of the DNS on the cluster nodes so the cluster couldn’t correctly resolve hostnames. Fixing the DNS issue, and deleting and re-installing the ClusterIssuer resolved the error.

    For additional troubleshooting tips, refer to the cert-manager documentation on the subject here.

  2. Check the issuing process

    With cert-manager, whenever we create a Certificate resource, cert-manager creates several resources. Those resources are linked and you can “walk” the link using kubectl describe {resourcetype} {resourcename} using the order resource as a starting point. What we are interested in here is the Events: section of the output which will help us figure out what’s wrong. Another, probably simpler, way to achieve the same result, is to query for all the events in the namespace we care about:

    kubectl get events -n test-cert
    LAST SEEN   TYPE      REASON               OBJECT                                                     MESSAGE
    32m         Normal    Started              challenge/test-certificate-wrong-1-4090149863-2764006135   Challenge scheduled for processing
    11m         Warning   PresentError         challenge/test-certificate-wrong-1-4090149863-2764006135   Error presenting challenge: Found no Zones for domain _acme-challenge.k3s.example.tech. (neither in the sub-domain nor in the SLD) please make sure your domain-entries in the config are correct and the API key is correctly setup with Zone.read rights.
    32m         Normal    Created              order/test-certificate-wrong-1-4090149863                  Created Challenge resource "test-certificate-wrong-1-4090149863-2764006135" for domain "k3s.example.tech"
    32m         Normal    WaitingForApproval   certificaterequest/test-certificate-wrong-1                Not signing CertificateRequest until it is Approved
    32m         Normal    WaitingForApproval   certificaterequest/test-certificate-wrong-1                Not signing CertificateRequest until it is Approved
    32m         Normal    WaitingForApproval   certificaterequest/test-certificate-wrong-1                Not signing CertificateRequest until it is Approved
    32m         Normal    WaitingForApproval   certificaterequest/test-certificate-wrong-1                Not signing CertificateRequest until it is Approved
    32m         Normal    WaitingForApproval   certificaterequest/test-certificate-wrong-1                Not signing CertificateRequest until it is Approved
    32m         Normal    cert-manager.io      certificaterequest/test-certificate-wrong-1                Certificate request has been approved by cert-manager.io
    32m         Normal    OrderCreated         certificaterequest/test-certificate-wrong-1                Created Order resource test-cert/test-certificate-wrong-1-4090149863
    32m         Normal    Issuing              certificate/test-certificate-wrong                         Issuing certificate as Secret does not exist
    32m         Normal    Generated            certificate/test-certificate-wrong                         Stored new private key in temporary Secret resource "test-certificate-wrong-rvtwc"
    32m         Normal    Requested            certificate/test-certificate-wrong                         Created new CertificateRequest resource "test-certificate-wrong-1"


    From here you can see that I requested a certificate for a domain I don’t own (example.tech)

Cleanup the test certificate
#

If you successfully managed to get a certificate using the staging ClusterIssuer, now it’s time to clean up the test certificate and the related secret. The quickest way to do so is to delete the whole namespace:

kubectl delete ns test-cert

Configure the production ClusterIssuer
#

Now, that we correctly obtained a staging certificate, it’s time to configure cert-manager to use the production API of Let’s Encrypt. To do so, we need to change the server URI and give it a different name, everything else stays the same as the staging ClusterIssuer, see the updated manifest here below:

  1. Create a file called clusterissuer-production.yml and paste the following manifest into it:
apiVersion: cert-manager.io/v1
kind: ClusterIssuer
metadata:
  name: letsencrypt-dns01-production-issuer
spec:
  acme:
    server: https://acme-v02.api.letsencrypt.org/directory    # Production API
    email: mail@mail.com                             # your email address for updates
    privateKeySecretRef:
      name: letsencrypt-dns01-production-private-key # Name of a secret used to store the ACME account private key
    solvers:
    - dns01:
        cloudflare:
          email: mail@mail.com                       # your cloudflare account email address
          apiTokenSecretRef:
            name: cloudflare-api-key-secret
            key: api-key

Caution

Make sure you replace the email in the manifest above.

  1. Create the staging ClusterIssuer in the cluster
kubectl apply -f clusterissuer-production.yml

At this point, let’s make sure that the production ClusterIssuer is ready as we did previously using:

kubectl get clusterissuer
NAME                                 READY   AGE
letsencrypt-dns01-staging-issuer     True    5m7s
letsencrypt-dns01-production-issuer  True    1m12s

Verify production ClusterIssuer installation
#

We can deploy a demo site using nginx and request a valid certificate from Let’s Encrypt to verify that we can successfully obtain a valid TLS certificate from Let’s Encrypt. Copy and paste the following manifest in a file called demosite.yml:

---
apiVersion: v1
kind: Namespace
metadata:
  name: demo-site
---
apiVersion: apps/v1
kind: Deployment
metadata:
  name: nginx-web
  namespace: demo-site
  labels:
    app: nginx-web
spec:
  replicas: 1
  selector:
    matchLabels:
      app: nginx-web
  template:
    metadata:
      labels:
        app: nginx-web
    spec:
      containers:
      - name: nginx
        image: nginx
        ports:
        - containerPort: 80
---
apiVersion: v1
kind: Service
metadata:
  name: nginx-web-service
  namespace: demo-site
  labels:
    app: nginx-web
spec:
  type: ClusterIP
  ports:
  - port: 80
    targetPort: 80
  selector:
    app: nginx-web
---
apiVersion: cert-manager.io/v1
kind: Certificate
metadata:
  name: k3s-tls-certificate
  namespace: demo-site
spec:
  secretName: k3s-maxdon-tech-tls             # Specify the name of the generated TLS certificate secret
  issuerRef:
    name: letsencrypt-dns01-production-issuer # Use the production ClusterIssuer
    kind: ClusterIssuer
  dnsNames:
  - k3s.maxdon.tech
---
apiVersion: traefik.io/v1alpha1
kind: IngressRoute
metadata:
  name: nginx-web-ingress
  namespace: demo-site
spec:
  entryPoints:
  - websecure                                 # Use websecure bind on 443 that's an entry point defined by Traefik, alongside a web one that it's bind on port 80
  routes:
  - match: Host(`k3s.maxdon.tech`)
    kind: Rule
    services:
    - name: nginx-web-service
      port: 80
  tls:
    secretName: k3s-maxdon-tech-tls         # Match the name of the secret that contains the certificate

Caution

Make sure you replace the host k3s.maxdon.tech with your domain.

Now let’s create all the resources in the cluster using our friend kubectl as follows:

kubectl apply -f demosite.yml

After a few minutes, you should be able to see a certificate in the demo-site namespace using the following command:

kubectl get certificate -n demo-site
NAME                  READY   SECRET                AGE
k3s-tls-certificate   True    k3s-maxdon-tech-tls   92s

At this point, we should be able to navigate in our browser to the website and verify that we have a valid TLS certificate, that has been issued by Let’s Encrypt, we can now delete the demosite resources using the following command:

kubectl delete -f demosite.yml

Conclusion
#

This was quite a lengthy post, but cert-manager makes it really easy for us to configure and automate certificate management. Beware that cert-manager doesn’t support all the domain registrar so if you still have to buy a domain and want to use cert-manager, make sure that you’re buying it from one of the supported ones.

Just to recap, to expose a service with its related TLS certificate we need to:

  1. Create a certificate resource to instruct cert-manager to request a certificate for us
  2. Instruct Traefik on which certificate to use, specifying the same secret name used in the certificate resource

At this point, we achieved all the goals from the first post:

  • Multinode k8s Cluster
  • Do not expose any internal service to the internet
  • Resolve internal services deployed on the cluster via domain name
  • Have free SSL certificates and automated certificate renewal

Pretty easy no?

In the next article we will look at automating the DNS records management that is still a manual process as of now, so stay tuned for the next one!

K3s on Raspberry PI - This article is part of a series.
Part 3: This Article
