Flash Raspberry Pi OS over the network with Ansible

Motivation

#

When I started building this homelab cluster I already had a several years of Terraform under my belt, so infrastructure-as-code felt natural to me. Everything in the cloud gets declared in HCL, planned, and applied. I wanted the same level of automation for my Raspberry Pis.

The obvious tool for this is Ansible. Unlike Terraform, Ansible doesn’t manage state files and doesn’t model resources, it just runs tasks over SSH, which is exactly what you need for configuring Linux boxes. To get up to speed quickly I picked up Ansible for DevOps by Jeff Geerling. I can’t recommend it highly enough, Jeff explains the concepts clearly and always gives practical, real-world examples.

I configured all the OS setup with Ansible, installing K3s, updating k3s, updating packages and everything else, but not everything was automated yet, OS updates still required a lot of time and manual thinkering. I got tired of flashing the OS manually. Every time I wanted to start fresh — to test a new Raspberry Pi OS release, to fix a wrong configuration, or just to rebuild the cluster cleanly I had to:

1. Pull each SD card (or NVMe drive) out of the Pi
2. Flash it with the Raspberry Pi Imager on my laptop
3. Put it back, power on, and wait

Multiply that by the number of nodes and it stops being fun. There had to be a better way to do this fully over the network, without touching any hardware.

This post explains how I automated the whole process.

The clever bit: overlayroot

#

The trickiest part of remote OS flashing is the chicken-and-egg problem: the Pi is booted from the disk you want to overwrite. If you write to /dev/sda (or /dev/nvme0n1) while the OS is running from it, you corrupt the live filesystem.

The solution is a package called overlayroot. When enabled, it remounts the root filesystem as a tmpfs overlay — all writes go to RAM while the underlying disk is left untouched and mounted read-only as the lower layer. From the Pi’s perspective the system still runs normally. From the flash perspective, the disk is free to overwrite.

Before overlayroot:           After overlayroot:
┌────────────────┐            ┌────────────────┐
│  / (ext4, rw)  │            │  / (overlay)   │ ← writes go here (RAM)
│  NVMe / SD     │            ├────────────────┤
└────────────────┘            │ upper (tmpfs)  │
                              ├────────────────┤
                              │ lower (ext4)   │ ← disk, now read-only
                              │  NVMe / SD     │   and safe to flash!
                              └────────────────┘

Once the Pi is in overlayroot, we can write a new OS image over the disk with dd while the system stays up long enough for Ansible to finish the task. The Pi then reboots cleanly into the new OS.

The playbook structure

#

The playbook is split into six plays that run in sequence: a preflight check, a normalization step to ensure a clean starting state, pivoting root to RAM with overlayroot, downloading and preparing the OS image, flashing it with dd, and finally verifying the new OS came up correctly.

The playbook is also idempotent: at the start it reads /etc/rpi-flash-version (written by cloud-init on first boot) and compares it against the target image URL. If they match, all plays are skipped.

# Check if the Pi is already running the target image
- name: Set already-flashed fact
  ansible.builtin.set_fact:
    rpi_already_flashed: >-
      {{
        _flash_ver_stat.stat.exists and
        (_flash_ver.content | b64decode | trim) == rpi_image_url
      }}

Configuration

#

All node-specific variables live in the inventory. The raspberrypis group (which contains all K3s nodes) defines the target image URL and common OS settings:

raspberrypis:
  hosts:
    pi-node-01:
      ansible_host: 192.168.20.1
    pi-node-02:
      ansible_host: 192.168.20.2
    pi-node-03:
      ansible_host: 192.168.20.3
    pi-node-04:
      ansible_host: 192.168.20.4
  vars:
    rpi_image_url: "https://downloads.raspberrypi.com/raspios_lite_arm64/images/raspios_lite_arm64-2025-12-04/2025-12-04-raspios-trixie-arm64-lite.img.xz"
    rpi_user: pi-adm
    rpi_timezone: "Europe/Amsterdam"
    rpi_packages:
      - vim
      - curl
      - git
      - htop
      - python3-pip

The role defaults provide sensible fallback values for everything else:

# roles/rpi-flash/defaults/main.yml
rpi_image_url: ""
rpi_image_path: "/tmp/{{ rpi_image_url | basename | regex_replace('\\.xz$', '') }}"

rpi_user: ""
rpi_timezone: ""
rpi_locale: "en_US.UTF-8"
rpi_keyboard_layout: "us"
rpi_ssh_public_key_path: "~/.ssh/id_ed25519.pub"
rpi_ssh_public_key: "{{ lookup('file', rpi_ssh_public_key_path) }}"
rpi_packages: []
rpi_dhcp: true

The SSH public key is read directly from your local ~/.ssh/id_ed25519.pub using Ansible’s lookup('file', ...), so you never have to paste keys manually.

The overlayroot play

#

This is where the magic happens. The play checks the current root filesystem type with findmnt. If the root is already an overlay (from a previous run), it skips the reboot and continues straight to the prepare phase. If not, it installs and configures overlayroot, then reboots:

# tasks/overlayroot.yml

- name: Check current root filesystem type
  ansible.builtin.command: findmnt -n -o FSTYPE /
  register: _current_rootfs
  changed_when: false

- name: Install overlayroot package
  ansible.builtin.apt:
    name: overlayroot
    state: present
  when: _current_rootfs.stdout != "overlay"

- name: Configure overlayroot (tmpfs, swap enabled)
  ansible.builtin.lineinfile:
    path: /etc/overlayroot.conf
    regexp: '^overlayroot='
    line: 'overlayroot="tmpfs:swap=1,recurse=0"'
  when: _current_rootfs.stdout != "overlay"

- name: Reboot into overlayroot
  ansible.builtin.reboot:
    reboot_timeout: 120
    post_reboot_delay: 20
  when: _current_rootfs.stdout != "overlay"

- name: Fail if not running in overlay
  ansible.builtin.fail:
    msg: "Expected overlay filesystem at /, got '{{ _rootfs_type.stdout }}'"
  when: _rootfs_type.stdout != "overlay"

Note the swap=1 option: with swap enabled, the overlay can spill over to the swapfile if RAM runs tight. This is important because we’ll be holding the entire OS image in RAM during the prepare phase.

Injecting cloud-init

#

Since Raspberry Pi OS is now based on Debian Trixie, it ships with cloud-init out of the box. This is a big deal for automation: it means we can inject a configuration file into the OS image before flashing and have the Pi fully configure itself on first boot — user accounts, SSH keys, packages, timezone, network — without any manual steps.

The prepare play doesn’t just copy the image — it modifies it before flashing. It mounts the FAT32 boot partition of the image file, then writes three cloud-init files into it:

• user-data — OS configuration (user, SSH key, packages, SSH hardening)
• network-config — network interface config (DHCP or static)
• meta-data — hostname for the NoCloud datasource

Here’s the user-data template that gets rendered per-host:

#cloud-config

hostname: {{ rpi_hostname | default(inventory_hostname) }}
manage_etc_hosts: true

users:
  - name: {{ rpi_user }}
    groups: [sudo, adm, dialout, gpio, i2c, spi]
    shell: /bin/bash
    sudo: ALL=(ALL) NOPASSWD:ALL
    lock_passwd: true
    ssh_authorized_keys:
      - {{ rpi_ssh_public_key }}

ssh_pwauth: false

timezone: {{ rpi_timezone }}
locale: {{ rpi_locale }}

packages:
{% for pkg in rpi_packages %}
  - {{ pkg }}
{% endfor %}

package_update: true

write_files:
  - path: /etc/ssh/sshd_config.d/hardening.conf
    owner: root:root
    permissions: '0644'
    content: |
      PermitRootLogin no
      PasswordAuthentication no
      PubkeyAuthentication yes
      MaxAuthTries 3
      X11Forwarding no

When the Pi boots into the new OS for the first time, cloud-init reads these files, creates the user, installs packages, configures SSH, and sets the timezone — all without any manual intervention.

The flash play

#

Once the image is decompressed and cloud-init is injected, the flash play takes over. The first thing it does — before writing anything — is remove the Pi’s old SSH host key from your local known_hosts. This is important: after flashing, the Pi will generate a new host key, and SSH would otherwise refuse to connect.

- name: Remove old SSH host key locally
  ansible.builtin.command: ssh-keygen -R "{{ ansible_host }}"
  delegate_to: localhost
  become: false

Then it runs dd:

- name: Write image to disk with dd
  ansible.builtin.shell: |
    dd if="{{ rpi_image_path }}" of="{{ flash_target }}" bs=4M conv=fsync status=progress

Dig deeper

#

• Jeff Geerling — Ansible for DevOps — the book I used to learn Ansible, highly recommended if you’re coming from a Terraform background
• overlayroot.conf — configuration reference for the overlayroot tool
• cloud-init NoCloud datasource — how cloud-init reads config from the boot partition without a metadata server
• cloud-init user-data reference — all the things you can configure in user-data

Conclusion

#

With this playbook, reflashing four Raspberry Pi nodes takes about as long as downloading the OS image once. No physical access, no SD card shuffling, no manual SSH key configuration. Just run the playbook, wait for the verify play to complete, and you’re ready to reinstall K3s.

It took a bit of effort to understand overlayroot and get all the edge cases right (spontaneous kernel panics, boot device detection, cloud-init injection), but the result is an automation I’m genuinely happy to use every time I need to start fresh.
